MÁY TÍNH CÔNG NGHIỆP ICO300- E3827-DIO-PB-DC

Giá: 18,100,000 VNĐ

Thông tin sản phẩm

Mã hàng: ICO300- E3827
Bảo hành: 12 tháng
Hãng sản xuất: AXIOMTEK
Xuất xứ: Taiwan

Mô tả sản phẩm

ICO300-E3827-DIO-PB-DC: Robust DIN-rail fanless embedded
system with Intel Atom® processor E3827 1.75 GHz, 4 COM, and
DIO
- PROCESSOR: Intel Atom® Processor E3827 1M Cache, 1.75 GHz
- RAM: 4GB DDRL3
- SSD: 128GB 2.5" SATA III
- ADAPTER: 2 wire AC to DC 12V adapter
- AC POWER CORD
- OS: Windows® 7 embedded, Windows® 8 embedded, Linux
support package, Windows® 10 IoT (trial version)
- I/O
4 x RS-232/422/485 (COM 1 to 4)
2 x USB 2.0
2 x 10/100/1000 Mbps Ethernet
1 x VGA
1 x DI/DO
HÃNG SẢN XUẤT AXIOMTEK - TAIWAN

Thêm vào giỏ hàng
CPU
  • Intel® Atom™ Processor E3815 (1.46GHz) or E3827 (1.75GHz)
Chipset
  • SoC integrated
System Memory
  • 1 x DDR3L-1333/1600 SO-DIMM, up to 8GB
COM
  • 4 x RS-232/422/485
USB
  • 2 x USB 2.0
Ethernet
  • 2 x 10/100/1000 Mbps Ethernet (Intel® I210-IT)
PoE
  • N/A
CANbus
  • N/A
Digital I/O
  • 1 x DI/DO (8 bit programmable, DB9 female connector)
Analog Input
  • N/A
Display
  • 1 x VGA
Expansion
  • 1 x Full-size PCI Express Mini Card slot
  • 1 x SIM card socket
Storage
  • 1 x CompactFlash™ (or mSATA)
  • 1 x SATA SSD (or HDD)
Others
  • RTC Battery function
  • 2 x Antenna
Power
  • 12 to 24 VDC, 1.21 to 0.66A (ICO300-E3815)
  • 12 to 24 VDC, 1.42 to 0.74A (ICO300-E3827)
Watchdog Timer
  • 255 levels, 1 to 255 sec.
Construction
  • Extruded aluminum and heavy-duty steel, IP40
Operating Temperature
  • -20°C to +70°C (-4°F to +158°F)
Relative Humidity
  • 10% to 95%
Vibration
  • 2 Gms (5 to 500Hz, amplitude 0.35 mm; operation/storage/transport)
Dimensions
(W x D x H)
  • 48 x 110 x 155 mm (1.88" x 4.33" x 6.10")
Weight (net/gross)
  • 1.0 kg (2.2 lb)/1.50 kg (3.3 lb)
Certifications
  • CE, FCC, UL
